Cast-In-Place Concrete Column with Corbel (with anchor bolts) – Tolerance Inspection Checklist
This digital template is developed to verify construction tolerances for cast-in-place concrete columns with corbels and anchor bolts. It ensures dimensional accuracy and compliance with international standards such as ACI 117, BS EN 13670, NZS 3109, and National Concrete Specifications.
Content Overview
· Detailed Tolerance Parameters: This checklist detailed outlines permitted deviations for various aspects such as column location, plumb, cross-sectional dimensions, and bearing surface levels.
· Corbel Specific Tolerances: It includes precise tolerance requirements for the specified length and width of corbels.
· Anchor Bolt Placement Accuracy: The document provides specific tolerances for the centerline, inclination, height, and distance between individual anchor bolts.
· Surface Irregularity Control: It addresses deviations from planeness/flatness over 3m and formed surface irregularities, promoting high-quality concrete finishes.
· Referenced Standards: The checklist integrates references to key international standards and specifications, including ACI 117, NZS 3109, BS EN 13670, and National Structural Concrete Specification.
Key Benefits of the Cast-In-Place Concrete Column with Corbel (with anchor bolts) – Tolerance Inspection Checklist
· Ensures Structural Accuracy: Verifies key construction tolerances for columns supporting slabs and beams.
· Reduced Rework Costs: Minimizes errors by early identification of out-of-tolerance deviations.
· Standard-Based Inspection: Align with ACI, BS, NZS, and AISC codes for global construction compliance.
· Supports On-Site QA/QC: Enables inspectors and engineers to systematically document actual versus permitted deviations.
· Improves Installation of Anchor Bolts: Helps ensure anchor bolts are installed with correct spacing, elevation, and inclination.
